 CMS  Version CMS Lite 32CH CMS Plus 64CH
(Live Free)
CMS Plus 64CH CMS Professional 96CH
 Product Picture
  Minimum System Requirements*
  Live CH  Request Up to 32CH Up to 64CH Up to 64CH Up to 96CH
  CPU Pentium CPU G6405 or above Intel core i7 7700 or above Intel core i7 7700 or above Intel core i7 7700 or above
  RAM 8GB or above 8GB or above 8GB (for 24CH manual recording) /
16GB (for 32CH & 64CH manual recording) or above
16GB or above
  Graphics  Card Intel UHD 610 or above GTX1050 2G or above GTX1050 2G or above GTX1050 2G or above
  Hard Drive Type at least 500GB space at least 500GB space at least 500GB (for 24CH manual recording) / 1TB (for 32CH & 64CH manual recording) space at least 500GB space
  Operating System Microsoft Windows 7/ 8 / 10 64 bit
 * When you're using CMS Lite on your laptop (not desktop), it's not recommended to use CMS Lite to connect to H.265 products since the connection may be
    affected by the performance of your laptop.
  Total number of servers
  in the distributed system
1 1 1 1 or above
  Total number of Live view
32 64 64 96
(For channels over 40, dual monitors are needed.)
  Multiple monitor display 1 Monitor 1 Monitor 4 Monitors Max. 8 Monitors Max.
  Camera Management No.
  (NVR/DVR/IP camera)
128 256 256 Unlimited
  Multicast Solution  No No No Yes
  Server & Client mode No Client mode only Client mode only Yes
  Proxy Server No No No Optional
  Use Proxy Server Stream Yes Yes Yes Yes
  Live View & Control
  Suported Video Format H.265 / H.264
  Predefined Display CH Number 32 64 64 96
  Sequence Display CH Number No No No 96
  Group View Display CH Number 16 32 32 36 Channel
(Group numbers unlimited)
  PTZ Control  Yes Yes Yes Yes
  Digital PTZ Control Function Yes Yes Yes Yes
  Digital PTZ Control  1X~11X
  Hotpoint Control Yes
  Manual Record to PC/Laptop & Audio Group
  Total Manual Record CH Number 16 0 24 32
  Manual & Event & Timer Record Yes No Yes Yes
  Audio Group function Yes Yes Yes Yes
  Total Audio Group CH Number 16 16 16 36
  E-MAP Basic Function Simple Simple Simple Yes
  Multi-layered Setup No No No Yes
  Intuitive management No No No Yes
  Event Notification No No No Yes
  Graphical Alarm Fence No No No Yes
  Event Management
  Event Pop-up No No Yes Yes
  Event Pop-up Live View CH Number No No 4CH 25CH Max.
  Audio Alert No No Yes Yes
  Playback and Backup
  Local Playback Channel 1CH Max. No 1CH Max. 1CH Max.
  Remote  Playback Channel  1CH Max. 1CH Max. 1CH Max. 9CH Max.
  Remote Backup Yes Yes Yes Yes
  Smart Search No No No Yes
  Digital PTZ Control  1X~11X 1X~11X 1X~11X 4X、8X
  Detail Check & Snapshot Yes
 Footage Conversion AVC/AVI
  Health Check
  Devices Status Simple Simple Yes Yes
  Computer Status No No No Yes
  Regular Report No No No Yes
  User  Account & Privilege Yes
  Windows  account sync Yes
  Other Functionality
  Matrix Display No No No Yes
  Thermal Camera support No No No Yes
  Intelligence Video Surveillance (OV IVS) No No No Yes
  Access Control  Systems No No No Optional
  License Plate Recognition Systems No No No Optional
  POS System No No No Optional
  Denso System No No No Optional
