AVH8536

8-bay 36CH H.265 NVR (w/Push Video, IVS)
  • H.265 Advanced Video Compression
  • 4K2K embedded Plug & Play NVR
  • Intelligent detection & advanced IOT platform
  • High accuracy event notification
Features
Specification
Apply Solution
Product Lineup
Contact Us

Download:


Tutorial

Datasheet

F/W

Product picture

Smart IOT

Dimenssion

Features

Features

Advantages of the complete product line
  • H.265 Compression Technology

    With this compression technology, the recording capacity is greatly enhanced as well as bandwidth saving for better efficiency and performance than the systems employing other compression formats.

  • Alarm Scenario Customization

    “Scenario” is a new feature allowing you to customize a series of actions which will be run automatically after the specified event occurs. There are several scenario templates for you to choose when and what to do after a specific event occurs.

  • Push Video & Push Status - Active Event Notification with EagleEyes App

    Push Video to send instant notifications for an alarm event when an alarm device is connected to the DVR.

    Push Status to send instant notifications for system events, such as video loss or HDD data removal.

  • 8-bay Storage Capacity

    To solve the large storage requirement of 4K2K recording, this NVR supports up to 8 hard disks to keep high quality H.265 video data without overwriting data so quickly. A power-saving mechanism is also adopted to reduce power consumption.

    • IVS

    IVS (Intelligent Video System) could be used to set a virtual detection line for people counting, virtual fence, and one-way pass. It's the advanced usage for motion detection to not only record but also summarize the detection data for further analysis.

  • Event Pop-up / Preview

    All events are listed on the right panel with corresponding event icons for you to quickly recognize the event type. The most current one will flash to catch your attention. Click one event and you’re able to preview the footage with pre-alarm images.

  • Spot Monitor

    In addition to the main display via the main HDMI-1 output, you can assign a secondary display via the HDMI-2, VGA or composite output to show live view, call monitor or event monitor.

Specification

Specification

Hardware
Video Input One LAN port (up to 36 IP cameras)
Video Output HDMI x 2 / VGA x 1 / Composite x 1
Video Output Resolution HDMI-1: Up to 3840 x 2160 (4K2K)
HDMI-2 & VGA: Up to 1920 x 1080 (Full HD)
Audio Output YES (Line out / HDMI)
Audio Input YES (Mic in)
Alarm I/O Alarm out only
HDD Storage** Eight 10TB hard disks
USB Ports USB 3.0 x 1 / USB 2.0 x 2
Ethernet LAN port 1000Mbps
Internet port 1000Mbps
Software
Video Compression Format H.265
Audio Compression Format G711
Local / Remote Display Mode 36CH
Local / Remote Playback Mode 36CH
Local Single Channel Playback YES
Record Stream Dual
Recording Mode Manual / Event / Alarm / Schedule
Recording Throughput Up to 480 IPS @ 8MP, 300Mbps
Up to 1080 IPS @ 5MP, 300Mbps
Pre-alarm Recording YES
Quick Search Time / Event
Event Notification Push Video / Push Status / Video Mail / Message Mail
Security Multiple user access levels with password
Remote Access
  1. Browsers such as Windows Edge, Internet Explorer, Google Chrome & Safari on Windows operating system
  2. CMS Lite, 32CH CMS software for Windows operating system
  3. EagleEyes on iOS & Android mobile devices
Max. Online User 20
Multicast YES
Seamless Recording YES
EaZy Networking YES
Spot Monitor Setup Call Monitor / Event Monitor / Live Monitor
(HDMI-2, VGA & Composite)
General
Alarm Scenario Setup YES
Alarm Pop-up & Preview YES
Power Source (±10%) DC19V / 3.42A
Power Consumption (±10%) 14.25W
(No hard disks connected)
Operating Temperature 10℃ ~ 40℃ (50℉~104℉)
Operating Humidity 10% ~ 85%
Dimensions (mm)*** 358mm(L) x 267mm(W) x 152mm(H)
Net Weight (kg) 5.8 kg
Minimum PC Browsing Requirements
  • Intel core i3 or higher, or equivalent AMD
  • 2GB RAM
  • AGP graphics card, Direct Draw, 32MB RAM
  • Windows 10, Windows 8, Windows 7, Windows Vista & Windows XP, DirectX 9.0 or later
  • Internet Explorer 7.x or later (Windows Edge not supported)
Optional Peripherals Full HD Matrix (HDM02) / PTZ Joystick (AVX102)
*The specifications are subject to change without notice
** HDDs are optional.
*** Dimensional tolerance: .±5mm
